Name: Header SBC IMCA 1 3/4" - 1 7/8" Left Side Only
SKU: 741-1186VL
Availability: InStock

Header SBC IMCA 1 3/4″ – 1 7/8″ Left Side Only

$144.86

Ideal for your IMCA modified with a S/B Chevy engine
Features stepped 1-3/4″ to 1-7/8″ primary tube
Collector has a 3-1/2″ diameter and measures 9″ in length
1/4″ flange has a squared style port design
Left Side Only

Compare

Description

Header Tube Type: Full-length

Finish: Temporary Paint

Flange Style: Standard

Primary Tube Diameter: 1-3/4″

Material Type: Steel

Color: Black

Weld-Up: No

Exhaust Port Shape: Square

Collector Diameter: 3-1/2 Inch

Collector Length: 8.75″

Flange Thickness: .25″

Port Height: 1.47″

Port Width: 1.68″

Drivers Side Dimension A: 23.60″

Drivers Side Dimension B: 5.50″

Drivers Side Dimension C: 20.50″

Passenger Side Dimension A: 14.30″

Passenger Side Dimension C: 30.00″

Hardware Included: Yes

Gasket(s) Included: Yes

Left Side Only

Info

These Schoenfeld long primary high velocity modified headers are the “baddest” headers for your IMCA modified with a S/B Chevy engine. Stepped 1-3/4″ to 1-7/8″ primary tubes and 3-1/2″ x 9″ collector. For standard port heads. Dirtworks style.

The paint on Schoenfeld headers protects them after the manufacturing process and during shipping – it is not designed as a final finish. It is recommended that this protective paint be stripped and a high heat coating/paint designed for use on headers.
